DMG Mori NHX 5000 2015

machine specifications

• Pallet Size:

  19.7" x 19.7"

• Maximum workpiece swing diameter :

  31.4"

• Maximum Workpiece Height:

  39.4"

• X-Axis Travel:

  28.7"

• Y-Axis Travel:

  28.7"

• Z-Axis Travel:

  34.6"

• B-Axis:

  0.001 deg

• Distance from Pallet Surface to Spindle Center:

  31.9"

• Distance From Pallet Center to Spindle Gauge Line PLane:

  37.4"

• Distance from floor surface to pallet surface:

  47.2"

• Pallet loading capacity:

  1,540lbs

• TOOL CAPACITY:

  60 ATC

• Spindle Speed:

  15,000 RPM

• Spindle Motor:

  40 HP

• Spindle Taper:

  CAT 40 Big Plus

• Rapid Traverse Rate:

  2,362 IPM

• Machine height:

  112.3"

• Floor space width x depth:

  121.2" x 188.3"

• Weight:

  26,400lbs
