Brother Speedio R450X1 2015 1
Brother Speedio R450X1 2015 2
Brother Speedio R450X1 2015 3
Brother Speedio R450X1 2015 4
Brother Speedio R450X1 2015 2
Brother Speedio R450X1 2015 2
Brother Speedio R450X1 2015 3
Brother Speedio R450X1 2015 4
Brother Speedio R450X1 2015 5
Brother Speedio R450X1 2015 6

Brother Speedio R450X1 2015

request quote

Open price not currently available. Please Contact Us

machine specifications

  • Z Axis Travel:

    12"

  • Table Size:

    23.6” x 11.8”

  • Maximum Weight on Table:

    265 / 441 lbs

  • X Axis Travel:

    17.7”

  • Y Axis Travel:

    12.6"

  • Z Axis Travel:

    12"

  • Spindle Nose to Table:

    7.9” – 19.9”

  • Spindle Taper:

    BT30 Taper Dual Contact

  • Spindle Speed:

    16,000 RPM

  • Spindle Motor:

    9.8/6.5 HP

  • Change Time (Tool to Tool) (Chip to Chip):

    .8 sec/ 1.6 sec

  • Cutting Feed Rate:

    1181 IPM

machine equipped with

  • 16000 RPM CTSI Spindle (Coolant Through Spindle Interface)
  • 9.8/6.5 HP Main Spindle Motor - IPM Motor Type
  • Spindle Taper Air Blast and Back Washing System
  • Automatic Grease Lubrication System
  • Chip Shower System
  • Manual Pulse Generator
  • Work Light Kit (2-Lights)
  • Spindle Override
  • Expanded Memory (500MB)
  • Shower Gun
  • TURBO LH/RH Side Discharge MH250 Conveyor with Tank & Interface
  • 435 PSI High Pressure Pump
  • Renishaw OMP40 Spindle Probe Package
  • Metrol tool setter and tool breakage detection (2 ea. 1 per pallet)
  • Big Plus Coolant Spindle With Tool Wash
  • 4TH-Axis Rotary Index Table: Nikken CNCZ-180LSABR2-QT
  • Pallet Changer

machine description

Used Brother Speedio R450X1. This pre-owned Vertical Machining Center is in great working condition and can be securely delivered to your facility floor. If you have any technical questions about this Brother Vertical Machining Center we can review machine specifications. To request a quote, inquire about rigging and trucking or to schedule an inspection, contact us today.
